Products Description
The upper part of the PV sandwich roof panel is integrated with a photovoltaic panel mount, which saves installation costs, is green and environmentally friendly, and can be installed more quickly.
Advantages of board type
1. The overlapping mother edge is treated with edge stacking technology to avoid edge corrosion due to lack of coating, prolong the service life of the board, increase strength, and avoid harm to construction personnel during installation.
2. The screws are hidden and have excellent waterproof properties, preventing corrosion of the screws and avoiding the occurrence of cold bridging phenomenon.
Board type characteristics
1. Upgraded roof panel crest structure, high and low crest design not only improves the load-bearing capacity of the roof panel, balances water flow, but also maximizes the use of raw material size to avoid waste.
2. The middle clamp type peak design allows for direct fixation of fixtures, making it easy and safe to achieve modular and rapid installation of roof photovoltaic solar energy systems, improving the effective utilization rate of the roof. The clamp type connection fixing method also avoids leakage hazards caused by roof drilling.
Product parameters
|
Plate type |
Photovoltaic energy-saving sandwich hidden nail roof panel |
|
Effective width(mm) |
950 |
|
Wave crest height(mm) |
40,22 |
|
Core material category |
PUR/PIR/Rock wool+PUR/Glass wool+PUR |
|
Core thickness(mm) |
50,75,100,150 |
|
Steel plate material |
Galvanized sheet, color coated sheet, aluminum alloy sheet |
|
Thickness of steel plate(mm) |
0.4,0.5,0.6,0.7,0.8 |
|
Appearance effect |
Double peak compression reinforcement in the outer panel, compression reinforcement in the inner panel, square wave, triangular reinforcement, and flat plate |
PNS Service
PNS has currently been exported to countries such as the United States, the United Kingdom, Puerto Rico, Ireland, Brazil, and Argentina. If you have a project that requires sandwich panels, please send us drawings and detailed requirements. We have a technical team to provide support and can help you calculate the specific quantity of panels and design edge finishing parts .
f a q
1.You are manufacture factory or trading company?
We are manufacture factory. You are welcomed to visit us at any time. In the workshop,it has a complete advanced equipment system for making steel structures and panels. So we can make sure the good quality and also the competitive price.
2.What is your difference with other products?
Our products have the environmental,protection,beautiful,insulation,fast installation,etc advantages.
Can you offer design service?
Yes,we have an engineer team and can design for you according to your requirements.Architectural drawing,structure diagram,processing detail drawing and installation drawing will be made and let you confirm in different time of the project.
4.What's the delivery time?
The delivery time depends on the size and quantity of building.Generally within 30 days after receiving the payment.And partial shipment is allowed for big order.
5.What's the payment term?
TT and L/C are acceptable; But T/T will be more appreciated. 30% deposit and balance before shipment.
6.Can you accept the inspection from a third party?
Yes. We have enough experience to cooperate with the inspection project and we have obtained ISO certification SGS certificate and the Australian official rockwool asbestos-free certification
