In the construction industry, color steel rock wool sandwich composite panel has become a very popular building material. This type of board has excellent thermal and acoustic insulation properties, and is easy to install, and is widely used in various construction projects.
The color steel rock wool sandwich composite panel is mainly composed of three parts, the sandwich layer rock wool board, and the inner and outer color steel plates. It adopts advanced production technology, strengthens the structural strength and fire performance of the plate, effectively prolongs the service life, and at the same time, the color and style of the color steel plate are diverse, which can meet the various needs of the building appearance design.
When installing the color steel rock wool sandwich composite panel, it is necessary to fix the plate on the wall with an angle iron coated with sealant, then lap the plates together, and seal the screw holes and other joints with sealant. This type of installation has a high resistance to wind pressure, water resistance, and aesthetics.
Rock wool composite board parameter table：
|
Product Name
|
Color Steel Rock Wool Sandwich Composite Panel |
|
Model
|
WL500-1000/RW
|
|
Thickness of panels
|
50/75/80/100/150/200mm
|
|
R-Value
|
1.32/ 1.97 / 2.11/ 2.63/3.95/5.26 ㎡.K/w
|
|
Thermal conductivity of Rock wool
|
≤0.038 w/(m. k)
|
|
Metal sheet(0.4-0.8mm)
|
1) color prepainted galvanized steel sheet
2) Aluminium zinc sheet
3) stainless steel sheet
4)Aluminum Magnesium Manganese sheet
|
|
Core material
|
Rock wool
|
|
Hydrophobic rate
|
98%
|
|
Glue connection
|
Bonding strength ≥0.06MPa
|
|
Gluing method
|
Automatic glue spraying
|
|
Density : core material
|
Rock wool: 80kg/m³ -120kg/m³
|
|
density: sealing side
|
PU:38-40kg/m3
PIR : 40-42kg/m3
|
The thermal insulation effect of color steel rock wool sandwich composite panel is very significant, and it is often used in the construction of walls, roofs, cold storage and industrial plants in construction projects, which can greatly reduce heat loss, make the indoor environment warm and comfortable, and save energy. At the same time, it also has a high sound insulation effect, which can effectively block the transmission of noise and maintain a quiet indoor environment.
Color steel rock wool sandwich composite panel is a very competitive building material, its use can not only improve the thermal insulation and sound insulation performance of the building, but also beautify the appearance of the building. If you are building or renovating your factory, color steel rock wool sandwich composite panel is definitely your indispensable choice.
For more price/information please contact us
