Product characteristics:
1. Fire resistance: Polyurethane is a Class B fireproof material that effectively reduces fire losses.
2. Thermal insulation and energy saving: Polyurethane thermal conductivity between 0.019-0.023w/m · k is an excellent thermal insulation material. Excellent nodal design ensures sealing performance and thermal insulation.
3. Good sound insulation: Good sound insulation, effectively reduce the interference of external sound.
4. Watertight/airtight: The hydrophobicity of the polyurethane material ≤ 5%, and the connection of the panels maintains good air tightness.
5. Stable and durable: The density is about 42kg/ m³, which is high in strength and stable for a long time.
6. Beautiful appearance: Screw-hidden node design, high flatness of the panels surface, rich color of the paint coating, long-lasting color.
Product Name | PUR exterior wall sandwich panel | PIR exterior wall sandwich panel |
Model | WL500-1000/PUR | WL500-1000/PIR |
Metal sheet | 0.4-0.8mm 1) color prepainted galvanized steel sheet 2) Aluminium zinc sheet, 3) stainless steel sheet, 4)Aluminum Magnesium Manganese sheet | |
Thickness | 50/75/80/100/120/150mm | |
Effective width | 500-1000mm (Regular 1000mm) | |
Length of panel | ≤11.8 meters | |
Core material | PU/PUR (Polyurethane) | PIR ( polyisocyanurate ) |
Density | 40~42 KG/M3 | 45~48KG/M3 |
Thermal conductivity (25℃) | ≤0.022/(m.k) | ≤0.0195w/(m.k) |
Heat-resistant range | -185℃ ~ 110℃（PUR foam) | -196℃ ~ 205℃(PIR foam) |
Long-term continuous use below 85℃(PUR sandwich panel) | Long-term continuous use below 150℃(PIR sandwich panel) | |
Closed cell rate | ≥97% | ≥97% |
Compression strength | 185 Kpa | 220 Kpa |
Water absorption rate | 2.5-3% | up to 0.9% |
Fireproof grade | B2 | B1 |
Combustion performance | ≥ D | ≥ B |
Color of steel plate | White grey,silver gray,sea-blue,crimson or as per RAL | |
Exterior / Interior surface profile | Flat,Relief,Small wave, Square wave | |
Painting | Polyester PE/SMP/HDP/PVDF coating etc. | |
Installation method | 1. horizontal ; 2. vertical | |
Joint type | hidden self-tapping screw connection | |
Our Advantages:
More than 15 years of factory specializing in the production of external wall panel, with its own design team
PU Foam Raw material is from famous supplier Huntsman,Bayer
Fastest delivery time of external wall panel 5-7 days.
High efficient supply ability 300,000 sqm monthly.
Precautions for installing polyurethane PIR external wall panel:
1, First of all, it must carry on the construction preparation before installation, include personnel, materials, etc. All will be well prepared.
2, Before the installation of external wall panel, it should check whether the verticality and levelness of metope purlin installation requirements, wall frame column vertical degree meets the requirement.
3, Before installation polyurethane external wall panel, it should first mounting plate bottom water retaining plate and the bottom of the window to block water board, water retaining plate and wall frame beam connection with self tapping screw fixation.
4. The pir external wall panel is connected to the ground.
Horizontal connection: The other end of the polyurethane sandwich panel is fixed with the round hole on the ground with a steel frame, and the two panels are connected by butt joints. If there is a crack at the connection, it can be filled with insulation.
Vertical connection: gaps between panels, using dedicated button grooves in fixed external wall panel.
