Products Description
These panels are usually composed of a core material, such as polyurethane foam, sandwiched between two layers of metal or other sturdy materials.
The concave and convex groove structure improves the airtightness of the joint of the panel, and has excellent heat insulation and waterproof performance; It has excellent heat insulation effect, greatly improves the airtight performance, and is more suitable for air-conditioned cold storage.
We have cold room insulation panels of different thickness, customers can choose the corresponding thickness according to the temperature of the cold storage.
The regular color of cold room insulation panels is white gray, the length can be cut according to the needs of customers, generally no more than a 40HQ maximum accommodating length of 11.8 meters, we have exported to many countries: In Peru, USA, Canada, Germany, Sri Lanka, Cameroon, Uganda, etc., our cold room insulation panels have been recognized and trusted by customers
Product Parameters
|
cold room sandwich panel core material parameter table |
||
|
Performance |
PUR |
PIR |
|
Density |
38-40Kg/m³ |
40-42Kg/m³ |
|
Themmal conductivity (25℃) |
≤0.028w/(m.k) |
≤0.026w/(m.k) |
|
Heat-resistantrange |
-185℃~110℃(PUR foam) |
-196℃~205℃(PIR foam) |
|
Long-temmcontinuous use below 85℃(PUR sandwich panel) |
Long-temmcontinuous use below 150℃(PIR sandwich panel) |
|
|
Closed cell rate |
≥97% |
≥97% |
|
Moisture Pemeance factor |
6.5 ng/(Pa.m~s) |
6.2 ng/(Pa.m~s) |
|
Water absorption rate |
2.5-3% |
up to 0.9% |
|
Fire Grade |
B2 |
B1 |
Application fields of cold room sandwich panels:
Food Industry:
cold room sandwich panels are a staple in the food industry, ensuring that perishable items like fruits, vegetables, meat, and dairy products are stored at optimal temperatures. This prevents spoilage and extends the shelf life of products.
The panels are made using high-quality materials key for withstanding the different weather elements. It is for this reason, you will find that the panels can be used in various environments.
Do you think installation is difficult or not? Actually, installation is very simple. Due to the light weight of these panels, most people can easily install them. Their light weight also means that there is no need for specialized equipment to properly set up the panels. This should also save you a lot of costs.
We have extensive industry experience, and if you have any questions, you can contact us for answers and more details. Let us help you obtain the best cold storage insulation board
Our free service hotline:+86 15981809760
Pre-sales Consultancy
1
>>
Confirmation of order
2
>>
Production
3
>>
Multi-Channel Shipping
4
>>
Confirmation of recei
5
>>
After-sale Services
6
FAQ
Q: Are you manufacture or trading company?
A: We are factory, welcome to visit our factory.We will provide airport pick-up service
Q: Where can your products be used?
A: Our products can be used in large industrial plants, warehouses, cold storage construction, etc.
Q: Will you provide technical services?
A:Of course, we have 15 technical experts with rich industry experience to serve you 24 hours a day.
Q:What is the MOQ?
A: 400 square meters, we need to ship by sea, 400 square meters can fill a container, maximizing the use of sea freight costs for you.
Q: Which countries have you exported to?
A: We have exported to Peru, New Zealand, Uganda, the United States, New Zealand, Australia, Russia, Mongolia, etc. 60+ countries and regions.
Q: What payment methods do you accept?
A: T/T, L/C, D/P,D/A, O/A etc. Production starts with 30% deposit, full payment is received and shipped.
Q: How long does it take to ship?
A: We use sea transportation and ship from Qingdao Port, which takes about 30 days.
